Sany SRSC4540G5 Reach Stacker Specs & Dimensions (2018 - 2026)
| Engine power | 265 kW |
| Weight | 81.5 t |
| Max. torque | 1785/1400 Nm |
| Wheel base | 7 m |
| Engine type | TAD1181VE |
| Total width | 6052 mm |
High-Performance Sany Sany SRSC4540G5 Reach Stacker Specs & Dimensions (2018 - 2026) Series
The Sany Sany SRSC4540G5 Reach Stacker Specs & Dimensions (2018 - 2026) provides maximum efficiency in your operations. From the 2018—2026 production series, it accelerates your workflow by offering industry-...
Technical Specifications
Detailed paramaters for Sany SRSC4540G5 Reach Stacker Specs & Dimensions (2018 - 2026)
| Weight | 81.5 t |
| Wheel base | 7 m |
| Engine type | TAD1181VE |
| Max. torque | 1785/1400 Nm |
| Total width | 6052 mm |
| Displacement | 10.84 l |
| Engine power | 265 kW |
| Model series | SRSC |
| Engine manuf. | Volvo |
| Emission level | V |
| Lifting height | 15.1 m |
| Standard tyres | 18.00-33 36PR |
| Turning radius | 9.1 m |
| Dimension lxwxh | 1398x921x1153 mm |
| No. of cylinders | 6 |
| Transmission type | W |
| Construction height | 4940 mm |
| Nominal load at COG | 45 t |
| Years of manufacture | 2018—2026 |
| Cylinder bore x stroke | 123x152 mm |
| Revolutions at max torque | 2100 rpm |
| Travel speed with / without load | 21/25 km/h |
